First of all, I'd like to give you some knowledge about the detection line of industrial endoscope. The detection lines of industrial endoscope can be divided into three types: 1. Soft detection line of tungsten wire mesh / metal mesh; 2; 2. Soft metal gooseneck detection line; 3. Flexible and hard glass fiber testing line.

那么如何選擇適合我們自己的呢?

So how to choose the right one for us?

鎢絲編網的軟質檢測線是直接與鏡頭連接在一起不可拆分的，適合對檢測空間較小、較短的工件及小管道進行檢測。

The soft detection line of tungsten wire netting is directly connected with the lens and can not be separated. It is suitable for the detection of workpieces and small pipes with small detection space and short detection time.

好處在于設備體積較小，整機便攜。

The advantages are small size and portable.

要說到弊端，可能就是檢測線比較脆弱，一旦出現幅度過大的彎折，可能導致里面的導絲斷掉，那么這整根檢測線就廢掉了。

When it comes to the disadvantages, it may be that the detection line is relatively fragile. Once there is too much bending, the guide wire inside may be broken, so the whole detection line will be discarded.

軟金屬鵝頸管的檢測線也是與鏡頭連在一起不可拆分的。

The detection line of soft metal gooseneck is also connected with the lens and cannot be separated.

但是它的特點也就很明顯了，它可以任意彎曲并確定方向，進入被檢測物體時不需要借助外力便可固定方向。

But its characteristic is very obvious. It can bend freely and determine the direction. When entering the detected object, it can fix the direction without the help of external force.


美中不足的是，它不適合對較大較長的管道或工件進行檢測。

The shortcoming is that it is not suitable for the detection of large and long pipelines or workpieces.

玻璃纖維的柔性硬質檢測線，它的鏡頭與檢測線是分開的，可以選擇更換不同功能、大小的鏡頭來達到咱們的檢測效果。

Flexible and hard glass fiber detection line, its lens and detection line are separated, you can choose to replace different functions, size of the lens to achieve our detection effect.

值得一提的是，與鎢絲編網的檢測線相比，玻璃纖維的檢測線對于檢測長度來說沒有限制，因為檢測線本身具有一定的硬度及柔韌度，所以可以根據大家要檢測物體的長短來定制，一般來說檢測80~100米是沒有問題的。

It is worth mentioning that, compared with the detection line of tungsten wire mesh, the detection line of glass fiber has no limitation on the detection length, because the detection line itself has a certain hardness and flexibility, so it can be customized according to the length of the object you want to detect. Generally speaking, it is no problem to detect 80 ~ 100 meters.

說到定制，是一家專業的工業內窺鏡制造商，可以滿足大家不同的需求。

When it comes to customization, we are a professional manufacturer of industrial endoscopes, which can meet different needs.

一般來說，我們要根據自己需要檢測物體的大小來判斷，如果被檢測物體內徑小于10mm且檢測長度不超過5m，就推薦用鎢絲編網/金屬編網的檢測線;如果被檢測物體內徑大于10mm且檢測長度超過5m，就推薦大家使用玻璃纖維柔性硬質的檢測線，方便長距離推送。

Generally speaking, we should judge according to the size of the object we need to detect. If the inner diameter of the object to be detected is less than 10 mm and the detection length is not more than 5 m, the detection line of tungsten wire mesh / metal mesh is recommended; If the inner diameter of the detected object is greater than 10 mm and the detection length is more than 5 m, it is recommended to use the flexible and hard detection line of glass fiber to facilitate long-distance push.

如果您看完了我的文章還沒有學會該如何選擇適合您的檢測線，就請您聯系我們吧!

If you haven't learned how to choose the right test line after reading my article, please contact us!
